Description:

RAC72 is an innovative fingerprint card access controller which fully integrates fingerprint and RFID technology. The very compact design makes it suitable for installation on door frame. RAC72 has standard Wiegand output to connect seamlessly with access controllers and relay output driver the electric lock directly. RAC72 can easily update the existing card readers for higher security level of fingerprint and card.

Function:

• Small in size and compact in design. Can be easily installed on doorframe

• New generation fully sealed, waterproof and dustproof fingerprint sensor. Rbio core fingerprint algorithm

• Steady algorithm platform for T&A and access control, high performance and reliability

• Easy user enrollment on the unit via Master Card or in the management software on computer

• Identification method: fingerprint, card, fingerprint + card

• RFID card module. Compatible with industrial standard

• Fingerprint Storage Capacity: 3000

• Communicate with computer via RS485, USB port

• Standard Wiegand26 output to connect with standard access controller

Specification:

Item Description

Processor AS602：32-bit RISC Core，120MHz，1MB FLASH，128K SRAM

Algorithm Power SupplyBio

Sensor RMF72 Optical Sensor

Sensor Wake Up Mode Presure Auto Wakeup Sensor

Resolution 500 DPI

Fingerprint Capacity3000

Log Capacity 10000

0Identification Mode FP,Card,FP+Card,

Identification Time <0.5 1000; <1.5 3000

FRR 0.001%

FAR 0.00001%

Communication Interface USB plug&play, RS485

Card Reader Module EM RFID Wiegand Output

Application:
